1. Even stirring: The stirring knife is composed of several sets of stirring arms to effectively cover all stirring areas.Rotation and revolution ensure that the material is stirred evenly.The mixing
1. Even stirring: The stirring knife is composed of several sets of stirring arms to effectively cover all stirring areas.
Rotation and revolution ensure that the material is stirred evenly.
The mixing path of the knife covers the whole mixing tank.
2. Special sprinkler design, spraying water widely and evenly.
3. Equipped with multiple shaft seal protection device, effectively prevent slurry leakage.
4. The transmission system (including the motor) is located below the mixing cylinder and is completely separated from the concrete.
5. Simple and lightweight equipment structure, easy installation, maintenance, low noise.
Model | Loading Capacity (L) | Discharge Capacity (L) | Productivity (m3/h) | Max.Grain Size （mm ） | Mixing Motor Power (kW) | Weight (Ton) | Dimension （mm） | Mix Time (s) |
JX-500 | 800 | 500 | ≥25 | 60 | 15 | 3.2 | 2250×2250×2680 | ≤30 |
JX-650 | 1050 | 650 | ≥30 | 60 | 22 | 4 | 2250×2250×2680 | ≤30 |
